Control Arm Dilemna

Post by John Brennan » Thu Nov 17, 2005 9:24 pm

Well, BAT sent me a set of Scorpio TCA's instead of XR4Ti ones, which I discovered upon trying to fit the new Powerflex bushings into the inner joint and discovering them to be too small. Further examination reveals that another difference between the two arms is that the Scorpio arm, besides having a slightly more robust appearance, is about 1/4" shorter between the outer TCA and the ball joint. This will reduce track accordingly, and slightly decrease negative camber as well.

Of course, BAT are out of stock until "after Thanksgiving at least," and therefore I have a couple of choices:

1) Replace the old arms, but with the new bushings, and wait for BAT to receive a shipment.

2) Use the Scorpio arms with Scorpio inner bushings.

3) Get XR4 arms from someone else (and pay lots more money, wait for shipping, etc.).

Peter at BAT was under the impression that the two arms were not interchangeable, that there may be problems with geometry, etc. Losing a little negative camber now could be made up for by slightly lowering the front end later, however. I am unsure as to any other deleterious effects of using Scorpio arms, e.g., clearance issues with wider tires on full-turn deflection.

Is anyone using Scorpio arms, or have personal experience with the subject? I need to get this thing back on the road...
This is my car, and these are my people!
1989 XR4Ti 5-Speed
2001 BMW Z3 3.0 5-Speed
2015 Fiesta ST 6-Speed
2015 Edge 3.5 V6 Auto/Paddles

User avatar
GeneticRehab
Level 5
Level 5
Posts: 685
Joined: Fri Oct 01, 2004 7:02 pm
Location: Some were in the USA

Post by GeneticRehab » Thu Nov 17, 2005 10:32 pm

Hey JB. I can get mooge greesable control arms for the xr. do you want me to price them and get you a part number?
Jason Liss
1989 XR Still in pieces

1986 XR Sold!

User avatar
John Brennan
Level 8
Posts: 11544
Joined: Wed Jun 18, 2003 4:19 pm
Location: Scottsdale, AZ "Summer Is Coming"

Post by John Brennan » Thu Nov 17, 2005 11:03 pm

Sure-- I'm not familiar with them. Are you saying that being greaseable, that the ball joints are serviceable? TIA.
This is my car, and these are my people!
1989 XR4Ti 5-Speed
2001 BMW Z3 3.0 5-Speed
2015 Fiesta ST 6-Speed
2015 Edge 3.5 V6 Auto/Paddles

User avatar
DPDISXR4Ti
Site Admin
Posts: 13511
Joined: Wed Jan 08, 2003 11:40 pm
Location: New York

Post by DPDISXR4Ti » Fri Nov 18, 2005 12:58 am

I doubt if the Moog's have replaceable joints, but with a zerk on them they'll be greaseable and thus should have a longer service life (if greased, of course).

What's really odd is that this evening (about the time John was typing his message), I was out in the garage with a XR and Scorpio control arm in each hand, comparing the two. :shock: I was considering how/if a Scorpio control arm could be used on a XR :shock: :shock: I just checked - nope, not a full moon tonight...

Any way, I didn't come up with a definitive answer, but here's a couple things to keep in mind...
1) Ball joint and inner through-bolt are larger on the Scorpio
2) The Scorpio anti-sway bar has a slightly larger spread to it

So here's what I'm thinking might work:
Scorpio control arm
Scorpio anti-sway bar (same size as Cossie bar, I believe)
XR hub modified for larger ball joint stud
XR subframe hole enlarged for larger Scorpio bolt (12mm?)

I suspect this combo will give you a wider track and more negative camber, as the total length of the Scorpio arm is greater than the XR. I'm not sure about caster.

Back to you Johnny... :wink:

User avatar
John Brennan
Level 8
Posts: 11544
Joined: Wed Jun 18, 2003 4:19 pm
Location: Scottsdale, AZ "Summer Is Coming"

Post by John Brennan » Fri Nov 18, 2005 2:22 am

Thanks, Ed. Ed MacMahon, ladies and gentlemen... thank you!

Well, Hell's Bells-- looks like I'll be slapping the old arms back on for the time being... need the car back.

As Patton once said, "I hate paying for the same real estate twice." :x
This is my car, and these are my people!
1989 XR4Ti 5-Speed
2001 BMW Z3 3.0 5-Speed
2015 Fiesta ST 6-Speed
2015 Edge 3.5 V6 Auto/Paddles

User avatar
Greenturbo
Level 6
Level 6
Posts: 933
Joined: Mon Apr 12, 2004 8:44 pm
Location: Edmonton, Alberta Canada
Contact:

Post by Greenturbo » Fri Nov 18, 2005 4:58 am

i got mine from BAT and some pollys, they work well
and the despite what he said abut the shipment taking a while.. they came promptly.. and they worked well

and you cant beat the price..

on a side not i remeber hthe guys at mc2 racing said that there was no need for alarger swaybar in the front.
MEMBER OF FAST COMPANY
*86 XR4TI*82 Mustang TT351*65 Mercury Comet*

User avatar
Grayson
Level 7
Level 7
Posts: 1318
Joined: Wed Jul 07, 2004 2:34 am
Location: West Chester, OH
Contact:

Post by Grayson » Fri Nov 18, 2005 10:08 am

Replaceable ball joints may not be "all that". After spending some intimate time with my F350 replacing the right front upper and lower ball joints, I'm not all that interested in replacing the ball joints on an XR anymore. Ok, I'm saying this mere hours after the experience from hell, so perhaps I'm a bit biased right now. Anyway, replacing press-fit ball joints is not a job you do without a press. A good press.

Anyone that's tried to call me the past two nights has surely become familiar with my voicemail message :(

User avatar
AnHonestCitizen
Level 4
Level 4
Posts: 407
Joined: Sat Sep 13, 2003 4:52 pm
Location: Washington D.C.

Post by AnHonestCitizen » Fri Nov 18, 2005 10:15 am

Here is a photo of three TCAs side-by-side:
